• Sound quality enthusiasts will appreciate the support for playing various types of music formats,
• including compatibility with FLAC files.
• Easy touchscreen sound customization is also available with its built-in 13-band EQ and digital time alignment
• Easy front panel connection for your USB enabled devices. These include mass storage devices such as iPods, smartphones and USB sticks. The USB input will allow you to charge and control music playback from your selected devices.
• A smartphone app can control most basic functions of the receiver via the paired phone's (iPhone or Android) Bluetooth connection.
• Direct Bluetooth keys give you quick access to answering and making calls, as well as entering the Bluetooth audio source. And the vertically aligned LCD screen ensures better visibility during daytime driving.

Specifications

FM

• Frequency range (MHz): 87.9 MHz to 107.9 MHz
• (No frequency) (200 kHz)
• Usable sensitivity: 8.2dBf
• Signal-to-noise ratio: 30 dB (0.71?V/75ohm)
• Silence sensitivity: 17.2dBf
• DIN S/N: 46 dB (2.0?V/75ohm)
• Frequency response (±3.0dB): 30Hz to 15kHz
• S/N(dB)È 64.0dB(MONO)
• Stereo separation: 40dB(1kHz)

AM

• Frequency range (kHz): 530kHz to 1700kHz
• (Frequency step): (10 kHz)
• Usable sensitivity: 29dB? (28.2?V)
• (S/N 20dB)

CD

• Laser diode: GaAlAs
• Digital Filter (D/A): 8x Oversampling
• Spindle speed: 500 to 200 rpm (CLV)
• Wow and flicker: Below measurable limit
• Response frequency: 20Hz to 20kHz(±1dB)
• Total harmonic distortion: 0.02% (1 kHz)
• Signal to noise ratio (dB): 94dB(1kHz)
• Dynamic range: 91dB
• Channel separation: 86dB
• MP3 Decoding: MPEG-1/2 Audio Layer-3 Compliant
• WMA Decoding: Compatible with WINDOWS MEDIA AUDIO
• AAC Decoding: AAC-LC ".aac" files


• Pre-output level (mV)/Load - Unbalanced: 4000mV/10k?
• Pre-output impedance: =<600ohm
• Speaker impedance: 4 to 8ohm

USB interface

• USB: USB 1.1 / 2.0 High Speed
• FAT12 / 16 / 32 file system
• Maximum supply current: DC5V (CC logo) 1.5A
• Response frequency: 20Hz to 20kHz(±1dB)
• Signal to noise ratio (dB): 98dB(1kHz)
• Dynamic range: 94dB
• Channel separation: 91dB
• MP3 Decoding: MPEG-1/2 Audio Layer-3 Compliant
• WMA Decoding: Compatible with Windows Media Audio
• AAC Decoding: AAC-LC files ".aac",".m4a"
• WAV Decoding: Linear PCM
• FLAC Decoding: FLAC file (up to 24bit/96kHz)

AUX input

• Frequency response: 20Hz to 20kHz ±3dB
• Maximum input voltage: 1000mV
• Input impedance: 30kohm

Bluetooth

• Version: Bluetooth 4.2
• Frequency range: 2.402 to 2.480GHz
• RF Output Power (EIRP): +4dBm (MAX), Power Class 2
• Maximum communication range: Line of sight approximately 10 m (32.8 ft)

General

• Working Voltage: 12V DC Car Battery
• Installation size
• (L)182 (mm) 7-3/16 (inch)
• (H)53 (mm) 2-1/16 (inch)
• (P)155.5 (mm) 6-1/8 (inches)
• Net Weight: 1.2 (kg) 2.7 (lbs) (Trim plate and mounting sleeve: included)
