TechCraft CAT8 shielded network cables transmit up to 40 Gbps
Heavy Duty High Speed Cat8 LAN Network Cable RJ45
24 AWG pure copper conductors
PVC Jacket
Maximum throughput: up to 40Gbps
Overview:
- Bandwidth: 2000MHz
- OD: 8.0mm
- Conductor: 24AWG (7/0.20), stranded bare copper
- Approvals: RoHS
- Connector: 50u'' Gold plated RJ45 connector
Physical characteristics:
- Cable type: Cat8 S/FTP
- Connector type: RJ45
- Wiring diagram: T568B
- Nominal temperature: -20C - +75C
- Nominal voltage: 30V
- CAT8 S/FTP [1P/24AWG (7*0.20BC)+AL)*4 + BRAID (16*8/0.12AL-MG)
Conductor (4 twisted pairs):
- Conductor Type: 24AWG (7/0.20), stranded bare copper
- Insulation: FOPE
- Diameter: 1.4+-0.05 mm
Connector type:
- Connector type: 8P8C RJ45 male shielded
- Connector material: PC
- Contact material: Copper alloy with 50 um gold plating
- Connector shielding: Shielded nickel plating
- Hood material: molded PVC boot
Global Cable:
- Sheath: PVC
- Minimum average thickness: 0.6 mm
- Outer diameter: 8.0 +- 0.20 mm
Electrical characteristics:
- Conductor DC resistance: 9.5 Ohm/100m (Maximum)
- Impedance: 100Ohm
- Capacity: 5600pf/100m
- Propagation delay: 545ns/100m (Maximum)
- Delay Skew: 45ns/100m (Maximum)
- Pass FLUKE channel test (100% test)
Cable markings:
25/40GBase-T S/FTP PATCH CABLE CATEGORY 8 24AWG 4 PAIRS ANSI/TIA-568.2-D
TechCraft CAT8 shielded network cables transmit up to 40 Gbps
Heavy Duty High Speed Cat8 LAN Network Cable RJ45
24 AWG pure copper conductors
PVC Jacket
Maximum throughput: up to 40Gbps
Overview:
- Bandwidth: 2000MHz
- OD: 8.0mm
- Conductor: 24AWG (7/0.20), stranded bare copper
- Approvals: RoHS
- Connector: 50u'' Gold plated RJ45 connector
Physical characteristics:
- Cable type: Cat8 S/FTP
- Connector type: RJ45
- Wiring diagram: T568B
- Nominal temperature: -20C - +75C
- Nominal voltage: 30V
- CAT8 S/FTP [1P/24AWG (7*0.20BC)+AL)*4 + BRAID (16*8/0.12AL-MG)
Conductor (4 twisted pairs):
- Conductor Type: 24AWG (7/0.20), stranded bare copper
- Insulation: FOPE
- Diameter: 1.4+-0.05 mm
Connector type:
- Connector type: 8P8C RJ45 male shielded
- Connector material: PC
- Contact material: Copper alloy with 50 um gold plating
- Connector shielding: Shielded nickel plating
- Hood material: molded PVC boot
Global Cable:
- Sheath: PVC
- Minimum average thickness: 0.6 mm
- Outer diameter: 8.0 +- 0.20 mm
Electrical characteristics:
- Conductor DC resistance: 9.5 Ohm/100m (Maximum)
- Impedance: 100Ohm
- Capacity: 5600pf/100m
- Propagation delay: 545ns/100m (Maximum)
- Delay Skew: 45ns/100m (Maximum)
- Pass FLUKE channel test (100% test)
Cable markings:
25/40GBase-T S/FTP PATCH CABLE CATEGORY 8 24AWG 4 PAIRS ANSI/TIA-568.2-D
TechCraft - FTP Network Cable with CAT8 Metal Connectors, Shielded, 2 Feet Long, Blue
- Regular price
- $9.97
- Sale price
- $9.97
- Regular price
-
item: 98-C-C8-02B
